High quality Industrial Artificial Rice Production Line Artificial Rice Extruder Machine

Product Description

The artificial rice processing machine adopts the broken rice, corn, millet, wheat, oats, buckwheat, bean, starch as main ingredient, and some other vitamin and mineral as part of ingredient. The material is extruded into rice shape by the twinscrew extruder, and dried in a rotary dryer to needed moisture content. Artificial rice machine extruding technique makes it possible to strengthen and solidify the micronutrient in the rice. This artificial rice can be mixed with natural rice prior to cooking as usual. When cooking is finished, its grains are not broken and there is no difference between the artificial rice and the natural one in viscosity, elasticity and taste.

Artificial rice making extruder

Artificial Rice Extruder Machine:

Mixing system---Conveying system----Extrusion system----Air blower----Drying system----Cooling system.

Artificial rice making extruder

2.Artifical rice production process:

Artificial rice making extruder

3.The equipment parameter of Artificial rice making extruder：

Model	Installed power	Actual consumption	Main power	Output	Dimension
DT65	34KW	28KW	22KW	100-150kg/h	240012001800mm
DT70	42KW	30kw	30kw	160-200kg/h	260012001800mm
DT75	85kw	60kw	55kw	200-300kg/h	260012001900mm
DT85	92kw	75kw	75kw	300-400kg/h	450016002000mm
DT90	135kw	91kw	75kw	400-600kg/h	450020002000mm

4.Detail of Artificial rice making extruder :

	Name: high speed mixer Dimension(m): 1.1×0.8×1.4 Motor Power: 4KW Speed: 400rpm Throughput: 30kg per loading (5-6 minutes per loading) Functions: mix raw powder material with water Features: 1. stainless steel material(1.5mm). 2. new handle-opened design of discharge holes,no materiel 3.High speed can mix material better than other slow mixer.
Name: screw conveyor Dimension(m): 3.2×0.6×0.7 Motor Power: 1.1KW Screw speed: 300rpm convey height range: 1.5~2.5M barrel diameter: Φ160mm Function: Power material can be conveyed in the stainless steel roller to the feeder of extruder without leaking, dust and pollution
	Name: Artificial Rice Production Line Artificial Rice Extruder Machine Dimension(m): 2.6×1.0×1.3 Main Motor Power:45KW Feeder motor:0.75kw Cutting motor: 1.5kw Heating power:10kw Extruder diameter:Φ70 mm Function: Extrude and cook raw material into different size and shapes Features: Screw material is 38CrMoAl with nitriding treatment, the hardness is 60HRC.. The barrel also use good material, hardness is 55HRC. The gear box has forced lubrication system. All motors can be adjusted the speed by Inverter. The Extruder can change different molds to produce different shapes product.
Name: multi-layer dryer Dimension(m): 8.4×1.3×1.8 Heating Power:60kw Motor power:0.75kw Belt speed:0.1-10M/minute Temperature: 20-200℃ Features: The net belt running speed can be controlled by Inverter, to change the food drying time in the dryer. Heating adopts the electric heating. It has automatic temperature Control system. The belt and the cover are all stainless steel.

Packaging & Shipping

1).Packaging: daub coal oil on the surface to protect the machine from moisture, Then cover with plastic film. Finally pack them with wooden case.

2)Customer's requirement is available.

3).If you want to know the transportation cost: by air-please tell me your airport name; by express-please tell me your detailed address(including zip code, house number, street, city, country); by ship-please tell me your delivery port.

Artificial rice making extruder

Artificial rice making extruder Technical Advantages:

Compact structure novel design and stable performance,developed on the base of like produces and requirements in the world market.It realizes high automation,convenient operation,low energy and small floor space,that assures all working procedures from feeding flour to finished once.The investment for this line is only one tenth of that larger size equipment ,especially suitable to small-size or self-owned enterprise.

Company Information

Artificial rice making extruder

Our Services

We will provide the most thoughtful services for our clients:

Before sale services:
1.Provide the free consultation of the equipment.
2.Provide the standard device and the flow chart.
3. According to the clients’ special requirement, offering the reasonable plan and free design helping to select the equipment.
Services during the sales:
1.Help client design the factory and offering professional advice, free engineering drawing for the factory layout
2.Welcome to visit our factory or the domestic clients’ factory.
3.Inspect the machine before leaving the factory.
After sale services:
1. Oversea install and debug the equipment.
2. Train the first-line operator.
3. Provide the basic formula.
4. Operation/ Service/ Maintenance Manual: Provided In English.
5. 1-2 engineers will be arranged for customer
